TECHNICAL SPECIFICATION

Printhead

Epson Dx5

Epson 3200 / Epson 4720

Printhead Quantity

3

3

Max Resolution

1440 dpi

3200 dpi

Number of Nozzles

1440 (8*180)

3200 (8*400)

Printing speed

2 pass – 60 m²/h

2 pass – 118 m²/h

4 pass – 45 m²/h

3 pass – 80 m²/h

6 pass – 31 m²/h

4 pass – 60 m²/h

8 pass – 23 m²/h

6 pass – 42 m²/h

Printing width

1800 mm

Media width

2000 mm

Color + gamut

CMYK – 16,7 million

Ink type

Eco solvent ink * Water-based ink * Sublimation ink

Printing Materials

Flex Banner, Vinyl, PVC, Backlit, Canvas

Heating System

Front, bed and rear body heater and extra dryer

Feeding method

Roll to roll, leaf

Rip Software

Maintop * Photoprint * Onyx

Color Management

ICC based, density and curves adjustment

Interface

USB 2.0 * USB 3.0

Computer System

Win7 * Win8 * Win10

Power Supply

220V * 10A * 50Hz/60Hz

File Forms

bmp, tiff, jpg, pdf…

Package Size

3140 x 940 x 1180 mm
